Technical Specifications
| Download Specification | |
| Product Specifications | |
|---|---|
| Package | Cut Tape (CT);Tape & Box (TB) |
| Product Status | Active |
| Type | Polymer |
| Capacitance | 3.3 mF |
| Tolerance | ±20% |
| Voltage - Rated | 6.3 V |
| ESR (Equivalent Series Resistance) | 11mOhm |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Applications | General Purpose |
| Ripple Current @ High Frequency | 5.3 A @ 100 kHz |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.591" (15.00mm) |
| Mounting Type | Through Hole |
| Package / Case |
|
