Technical Specifications
| Download Specification | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Type | Polymer |
| Capacitance | 6.8 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | 80mOhm |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Ratings | AEC-Q200 |
| Applications | General Purpose |
| Ripple Current @ High Frequency | 1.2 A @ 100 kHz |
| Lead Spacing | 0.098" (2.50mm) |
| Size / Dimension | 0.248" Dia (6.30mm) |
| Height - Seated (Max) | 0.236" (6.00mm) |
| Mounting Type | Through Hole |
| Package / Case |
|
