Technical Specifications
| Download Specification | |
| Product Specifications | |
|---|---|
| Package | Tray |
| Product Status | Active |
| Type | Hybrid |
| Capacitance | 780 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | 87mOhm |
| Lifetime @ Temp. | 8000 Hrs @ 125°C |
| Operating Temperature | -40°C ~ 125°C |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Features | High Vibration |
| Ripple Current @ Low Frequency | 7.78 A @ 100 Hz |
| Ripple Current @ High Frequency | 38.9 A @ 100 kHz |
| Size / Dimension | 0.638" Dia x 1.366" L (16.20mm x 34.70mm) |
| Mounting Type | Through Hole |
| Package / Case |
|
