Technical Specifications
| Download Specification | |
| Product Specifications | |
|---|---|
| Package | Tape & Reel (TR);Cut Tape (CT);Digi-Reel® |
| Product Status | Active |
| Type | Polymer |
| Capacitance | 10 µF |
| Tolerance | ±20% |
| Voltage - Rated | 16 V |
| ESR (Equivalent Series Resistance) | 40mOhm |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Applications | Decoupling |
| Ripple Current @ High Frequency | 2 A @ 100 kHz |
| Size / Dimension | 0.287" L x 0.169" W (7.30mm x 4.30mm) |
| Height - Seated (Max) | 0.083" (2.10mm) |
| Mounting Type | Surface Mount |
| Package / Case | 2917 (7343 Metric) |
