Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Tube |
| Product Status | Discontinued at Digi-Key |
| Applications | Board Mount |
| Pressure Type | Vented Gauge |
| Operating Pressure | 0.04PSI (0.25kPa) |
| Output Type | Wheatstone Bridge |
| Output | 0 mV ~ 7 mV (4.5V) |
| Accuracy | ±0.5% |
| Voltage - Supply | 6V |
| Port Size |
|
| Port Style | Barbless |
| Features | Temperature Compensated |
| Termination Style | PC Pin |
| Maximum Pressure | 0.04PSI (0.25kPa) |
| Operating Temperature | -25°C ~ 85°C |
| Mounting Type | Through Hole |
| Package / Case | 4-SIP Module |
