Download the specification sheet
|
|
| Package |
Tube
|
| Product Status |
Active
|
| Applications |
Board Mount
|
| Pressure Type |
Vented Gauge
|
| Operating Pressure |
0.04PSI (0.25kPa)
|
| Output Type |
Analog Voltage
|
| Output |
0.25 V ~ 4.25 V
|
| Accuracy |
±0.25%
|
| Voltage - Supply |
4.5V ~ 5.5V
|
| Port Size |
- Male - 0.19" (4.83mm) Tube
- Dual
|
| Port Style |
Barbless
|
| Features |
- Amplified Output
- Temperature Compensated
|
| Termination Style |
PC Pin
|
| Maximum Pressure |
3.61PSI (24.92kPa)
|
| Operating Temperature |
-40°C ~ 125°C
|
| Mounting Type |
Through Hole
|
| Package / Case |
4-SIP Module
|
