Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Tape & Reel (TR);Cut Tape (CT) |
| Product Status | Obsolete |
| Tail Type | No Tail |
| Termination | Solder |
| Length - Overall | 0.290" (7.37mm) |
| Accepts Pin Diameter | 0.028" ~ 0.033" (0.71mm ~ 0.84mm) |
| Mounting Hole Diameter | 0.062" (1.57mm) |
| Flange Diameter | 0.080" (2.03mm) |
| Socket Depth | 0.148" ~ 0.260" (3.76mm ~ 6.60mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Tin |
| Contact Finish Thickness | 150.0µin (3.81µm) |
