Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Tape & Reel (TR);Cut Tape (CT) |
| Product Status | Obsolete |
| Tail Type | No Tail |
| Termination | Solder |
| Length - Overall | 0.184" (4.67mm) |
| Accepts Pin Diameter | 0.014" ~ 0.026" (0.36mm ~ 0.66mm) |
| Mounting Hole Diameter | 0.052" (1.32mm) |
| Flange Diameter | 0.075" (1.91mm) |
| Socket Depth | 0.100" ~ 0.170" (2.54mm ~ 4.32mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Tin |
| Contact Finish Thickness | 100.0µin (2.54µm) |
