Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Tape & Reel (TR) |
| Product Status | Obsolete |
| Tail Type | No Tail |
| Termination | Solder |
| Length - Overall | 0.260" (6.60mm) |
| Accepts Pin Diameter | 0.037" ~ 0.041" (0.94mm ~ 1.04mm) |
| Mounting Hole Diameter | 0.069" (1.75mm) |
| Flange Diameter | 0.088" (2.24mm) |
| Socket Depth | 0.210" (5.33mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
