Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Tube |
| Product Status | Obsolete |
| Circuit | SPST |
| Number of Positions | 9 |
| Current Rating (Amps) | 25mA |
| Voltage Rating | 24VDC |
| Actuator Type | Piano |
| Actuator Level | Raised |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Height Above Board | 0.290" (7.37mm) |
| Mounting Type |
|
| Termination Style | PC Pin |
| Pitch |
|
| Washable | Yes |
| Features | Tape Seal |
| Operating Temperature | -55°C ~ 105°C |
