Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Obsolete |
| Tail Type | No Tail |
| Termination | Solder |
| Length - Overall | 0.178" (4.52mm) |
| Accepts Pin Diameter | 0.013" ~ 0.020" (0.33mm ~ 0.51mm) |
| Mounting Hole Diameter | 0.041" (1.04mm) |
| Flange Diameter | 0.059" (1.50mm) |
| Socket Depth | 0.165" (4.19mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
