Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | No Tail |
| Termination | Solder |
| Length - Overall | 0.143" (3.63mm) |
| Accepts Pin Diameter | 0.037" ~ 0.040" (0.94mm ~ 1.02mm) |
| Mounting Hole Diameter | 0.072" (1.83mm) |
| Flange Diameter | 0.089" (2.26mm) |
| Socket Depth | 0.130" (3.30mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
