Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Circuit | SPST-NO |
| Switch Function | Off-Mom |
| Contact Rating @ Voltage | 0.05A @ 24VDC |
| Actuator Type | Standard |
| Mounting Type |
|
| Actuator Length, Right Angle | 6.15mm |
| Actuator Orientation | Side Actuated |
| Termination Style | PC Pin |
| Outline | 7.11mm x 6.60mm |
| Illumination | Non-Illuminated |
| Operating Force | 160gf |
| Operating Temperature | -40°C ~ 105°C |
