Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Tape & Reel (TR);Cut Tape (CT);Digi-Reel® |
| Product Status | Active |
| Circuit | SPST |
| Number of Positions | 8 |
| Current Rating (Amps) | 25mA |
| Voltage Rating | 24VDC |
| Actuator Type | Slide (Standard) |
| Actuator Level |
|
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Height Above Board | 0.091" (2.30mm) |
| Mounting Type | Surface Mount |
| Termination Style | Gull Wing |
| Pitch |
|
| Washable | Yes |
| Features | Tape Seal |
| Operating Temperature | -30°C ~ 85°C |
