Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | Crimp |
| Termination | Solder |
| Length - Overall | 0.518" (13.16mm) |
| Accepts Pin Diameter | 0.025" ~ 0.037" (0.64mm ~ 0.94mm) |
| Accepts Square Pin Size | 0.025" (0.64mm) |
| Pin Hole Diameter | 0.051" (1.30mm) |
| Socket Depth | 0.200" (5.08mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
