Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | Crimp |
| Termination | Solder |
| Length - Overall | 0.518" (13.16mm) |
| Accepts Pin Diameter | 0.045" ~ 0.065" (1.14mm ~ 1.65mm) |
| Pin Hole Diameter | 0.088" (2.24mm) |
| Flange Diameter | 0.129" (3.28mm) |
| Socket Depth | 0.214" (5.44mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
