Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | No Tail |
| Termination | Solder |
| Length - Overall | 0.166" (4.22mm) |
| Accepts Pin Diameter | 0.015" ~ 0.025" (0.38mm ~ 0.64mm) |
| Pin Hole Diameter | 0.043" (1.09mm) |
| Mounting Hole Diameter | 0.056" (1.42mm) |
| Flange Diameter | 0.072" (1.83mm) |
| Socket Depth | 0.147" (3.73mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
