Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | No Tail |
| Termination | Press-Fit |
| Length - Overall | 0.120" (3.05mm) |
| Accepts Pin Diameter | 0.040" ~ 0.050" (1.02mm ~ 1.27mm) |
| Pin Hole Diameter | 0.068" (1.73mm) |
| Mounting Hole Diameter | 0.100" (2.54mm) |
| Flange Diameter | 0.100" (2.54mm) |
| Socket Depth | 0.097" (2.46mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
