Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | No Tail |
| Termination |
|
| Length - Overall | 0.105" (2.67mm) |
| Accepts Pin Diameter | 0.037" ~ 0.043" (0.94mm ~ 1.09mm) |
| Pin Hole Diameter | 0.059" (1.51mm) |
| Mounting Hole Diameter | 0.085" (2.16mm) |
| Flange Diameter | 0.088" (2.24mm) |
| Socket Depth | 0.096" (2.44mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 10.0µin (0.25µm) |
