Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | No Tail |
| Termination | Press-Fit |
| Length - Overall | 0.064" (1.63mm) |
| Accepts Pin Diameter | 0.008" ~ 0.013" (0.20mm ~ 0.33mm) |
| Pin Hole Diameter | 0.021" (0.53mm) |
| Mounting Hole Diameter | 0.039" (0.99mm) |
| Flange Diameter | 0.038" (0.97mm) |
| Socket Depth | 0.055" (1.40mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
