Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | No Tail |
| Termination |
|
| Length - Overall | 0.068" (1.73mm) |
| Accepts Pin Diameter | 0.018" ~ 0.024" (0.46mm ~ 0.60mm) |
| Mounting Hole Diameter | 0.045" (1.14mm) |
| Flange Diameter | 0.048" (1.22mm) |
| Socket Depth | 0.066" (1.68mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
