Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | Standard Tail |
| Termination | Solder |
| Length - Overall | 0.300" (7.62mm) |
| Accepts Pin Diameter | 0.015" ~ 0.020" (0.38mm ~ 0.51mm) |
| Pin Hole Diameter | 0.031" (0.79mm) |
| Mounting Hole Diameter | 0.020" (0.51mm) |
| Flange Diameter | 0.041" (1.04mm) |
| Tail Diameter | 0.018" (0.46mm) |
| Socket Depth | 0.150" (3.81mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Tin-Lead |
| Contact Finish Thickness | 100.0µin (2.54µm) |
