Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | No Tail |
| Termination | Solder |
| Length - Overall | 0.309" (7.85mm) |
| Accepts Pin Diameter | 0.065" ~ 0.082" (1.65mm ~ 2.08mm) |
| Pin Hole Diameter | 0.107" (2.72mm) |
| Mounting Hole Diameter | 0.159" (4.04mm) |
| Flange Diameter | 0.189" (4.80mm) |
| Socket Depth | 0.260" (6.60mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
