Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Tape & Reel (TR);Cut Tape (CT) |
| Product Status | Active |
| Tail Type | No Tail |
| Termination | Solder |
| Length - Overall | 0.107" (2.72mm) |
| Accepts Pin Diameter | 0.037" ~ 0.043" (0.94mm ~ 1.09mm) |
| Pin Hole Diameter | 0.063" (1.60mm) |
| Mounting Hole Diameter | 0.075" (1.91mm) |
| Flange Diameter | 0.089" (2.26mm) |
| Socket Depth | 0.095" (2.41mm) |
| Contact Material | Brass Alloy |
| Contact Finish | Tin |
| Contact Finish Thickness | 200.0µin (5.08µm) |
