Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | No Tail |
| Termination | Solder |
| Length - Overall | 0.132" (3.35mm) |
| Accepts Pin Diameter | 0.020" ~ 0.032" (0.51mm ~ 0.81mm) |
| Pin Hole Diameter | 0.047" (1.19mm) |
| Mounting Hole Diameter | 0.082" (2.08mm) |
| Flange Diameter | 0.092" (2.34mm) |
| Socket Depth | 0.132" (3.35mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Tin-Lead |
| Contact Finish Thickness | 200.0µin (5.08µm) |
