Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | No Tail |
| Termination | Solder |
| Length - Overall | 0.225" (5.72mm) |
| Accepts Pin Diameter | 0.048" ~ 0.064" (1.22mm ~ 1.63mm) |
| Pin Hole Diameter | 0.088" (2.24mm) |
| Mounting Hole Diameter | 0.102" (2.59mm) |
| Flange Diameter | 0.118" (3.00mm) |
| Socket Depth | 0.225" (5.72mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
