Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Tape & Reel (TR);Cut Tape (CT) |
| Product Status | Active |
| Tail Type | No Tail |
| Termination | Solder |
| Length - Overall | 0.078" (1.98mm) |
| Accepts Pin Diameter | 0.015" ~ 0.022" (0.38mm ~ 0.56mm) |
| Pin Hole Diameter | 0.031" (0.79mm) |
| Mounting Hole Diameter | 0.047" (1.19mm) |
| Flange Diameter | 0.061" (1.55mm) |
| Socket Depth | 0.069" (1.75mm) |
| Contact Material | Brass Alloy |
| Contact Finish | Tin |
| Contact Finish Thickness | 200.0µin (5.08µm) |
