Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | Crimp |
| Termination | Solder |
| Length - Overall | 0.530" (13.46mm) |
| Accepts Pin Diameter | 0.032" ~ 0.046" (0.81mm ~ 1.17mm) |
| Pin Hole Diameter | 0.064" (1.63mm) |
| Flange Diameter | 0.122" (3.10mm) |
| Socket Depth | 0.200" (5.08mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Tin-Lead |
| Contact Finish Thickness | 200.0µin (5.08µm) |
