Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | Wire Wrap |
| Termination | Press-Fit |
| Length - Overall | 0.812" (20.62mm) |
| Accepts Pin Diameter | 0.022" ~ 0.032" (0.56mm ~ 0.81mm) |
| Pin Hole Diameter | 0.051" (1.30mm) |
| Mounting Hole Diameter | 0.080" (2.03mm) |
| Flange Diameter | 0.085" (2.16mm) |
| Tail Diameter | 0.025" (0.64mm) Square |
| Socket Depth | 0.270" (6.86mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Tin-Lead |
| Contact Finish Thickness | 200.0µin (5.08µm) |
