Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | No Tail |
| Termination | Press-Fit |
| Length - Overall | 0.173" (4.39mm) |
| Accepts Pin Diameter | 0.015" ~ 0.025" (0.38mm ~ 0.64mm) |
| Pin Hole Diameter | 0.043" (1.09mm) |
| Mounting Hole Diameter | 0.057" (1.45mm) |
| Flange Diameter | 0.072" (1.83mm) |
| Socket Depth | 0.148" (3.76mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Tin-Lead |
| Contact Finish Thickness | 100.0µin (2.54µm) |
