Technical Specifications
| Download the specification sheet | |
| Product Specifications | |
|---|---|
| Package | Bulk |
| Product Status | Active |
| Tail Type | No Tail |
| Termination | Solder |
| Length - Overall | 0.275" (6.99mm) |
| Pin Hole Diameter | 0.052" (1.32mm) |
| Mounting Hole Diameter | 0.061" (1.55mm) |
| Flange Diameter | 0.072" (1.83mm) |
| Tail Diameter | 0.052" (1.32mm) |
| Socket Depth | 0.228" (5.79mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
